Ruijie Reyee RG-RAP2260(G) AX1800 Wi-Fi 6 Dual-Band Ceiling Access Point

Ruijie Reyee RG-RAP2260(G) AX1800 Wi-Fi 6 Dual-Band Ceiling Access Point. AX1800 Dual Band Ceiling Mount Wi-Fi6 Access Point 1201Mbps at 5GHz + 574Mbps at 2.4GHz; 2 10/100/1000base-t Ethernet uplink port.

Key Specifications

• AX1800 Dual Band Ceiling Mount Wi-Fi6 Access Point
• 1201Mbps at 5GHz + 574Mbps at 2.4GHz
• 2 10/100/1000base-t Ethernet uplink port
• Product Type: Ceiling AP
• Radio design: Dual-radio; 4 spatial streams; 2.4 GHz: 2 x 2, MU-MIMO; 5 GHz: 2 x 2, MU-MIMO
• Maximum wireless data rate: 1774 Mbps
• 5 GHz wireless data rate: 1201 Mbps
• 2.4 GHz wireless data rate: 573 Mbps
• Antenna: 2.4 GHz: 2 built-in omnidirectional antennas5 GHz: 2 built-in omnidirectional antennas
• Product dimensions (W x D x H): 194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) (excluding the mounting bracket)
• Color: White
• Weight: ≤ 0.55 kg (1.21 lbs.) (without packaging materials)
• Number of 10/100/1000BASE-T ports: 2
• Power supply: DC power adapter; PoE/PoE+Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred.
• Local power supply: Yes, one DC power connector (12 V, 1.5 A)
• Maximum power consumption: 15.5 W
• Operating temperature: 0°C to 40°C (32°F to 104°F)
• Mounting options: Ceiling/Wall
• IP rating: IP41
• Maximum number of associated wireless clients: 64 (2.4 GHz); 256 (5 GHz); 256 (2.4 GHz and 5 GHz enabled)
• Maximum number of devices that can be managed: 300
• Warranty: 3 years
• Management: Ruijie Cloud / Reyee app, local eWeb
